Захранване Gigabyte P650G PCIE 5.1
ATX 3.1 and
PCIe Gen 5.1 Ready
Designed to meet the demands of next-gen systems, this ATX 3.1 compliant PSU handles up to 3× GPU and 2× system power excursions with 70% efficiency at low loads. The high-performance native 16-pin cable delivers up to 300W for PCIe Gen 5 graphics cards, such as the GeForce RTX™ 50 Series and beyond.
80 PLUS
GOLD CERTIFIED
Achieving 90% efficiency at a 50% load, this 80 PLUS Gold certified PSU reduces power loss, minimizes heat generation, and lowers fan noise, ensuring both performance and energy savings.
HIGH QUALITY
JAPANESE CAPACITORS
The primary capacitors are sourced from top-tier Japanese manufacturers, delivering a premium and stable power supply that effectively extends the product's lifespan.
120MM SILENT HYDRAULIC
BEARING (HYB) FAN
The 120mm fan detects the current power utilization and temperature, automatically adjusting its rotational speed to minimize noise.The Hydraulic Bearing fan offers a longer and more stable lifespan in comparison to traditional sleeve fan.
Type
Intel Form Factor ATX 12V v3.1
PFC
Active PFC(>0.9 typical)
Input Voltage
100-240 Vac
Input Current
10-6A
Input Frequency
60-50 Hz
Output Capacity
650W
Характеристики
| Размери | 150 x 140 x 86 mm |
| Fan Type | 120mm HYB Fan |
| 80 PLUS | Gold |
| Efficiency | 90% at typical load |
| MTBF | >100,000 hours |
| Protections | OVP/OPP/SCP/UVP/OCP/OTP |
| Power Good Signal | 100-150ms |
| Hold Up Time | >17ms |
| Cable Type | Embossed |
| Конектори | ATX/MB 20+4 Pin x 1 : 600mm*1 |
