Захранване Chieftec Vega M White
The CHIEFTEC Vega M Series power supply is built to Intel’s ATX 12V 3.1 standard and supports PCIe GEN5 with 80PLUS Gold certified efficiency. It prioritizes a competitive price-to-performance ratio up to 850W while maintaining the trusted Chieftec quality. The Vega M Series features LLC Half-Bridge converter with DC-to-DC technology to provide enhanced power efficiency and stability.
The full-modular design with extra- long black cables make it suitable for mainstream gamers to build their system, even in larger PC cases. Additionally, its 135mm fluid dynamic bearing (FDB) silent fan optimizes the balance between cooling performance and noise levels.
The Vega Series is your trusted reliable choice for all computing needs incorporating all necessary modern protection and safety features.
Technical data
Характеристики
| AC Input | 100 - 240V~ / 10 - 5A |
| Честота | 50 - 60Hz |
| 5V | 20A |
| 3,3V | 20A |
| 5V & +3,3V combined | 100W |
| 12V1 | 62.5A |
| 12V2 | - |
| 12V1, +12V2 combined | 750W |
| P.F | >0.9 |
| 12V | 0.3A / 3.6W |
| 5VSB | 3.0A / 15W |
| Maximum Power | 750W |
| Конектори | Да |
| 20+4 PIN ATX | 1 |
| 8 PIN EPS (8/4+4) | 1/1 |
| 8 PIN PCIe (6+2) | 4 |
| 16 PIN 12V - 2 x 6 | 1 |
| SATA | 6 |
| MOLEX | 3 |
| Cable length (mm) | Да |
| 20+4 PIN ATX | 600 |
| 8 PIN EPS (4+4) | 650/150 |
| 8 PIN PCIe (6+2) | 2 x 600/150 |
| 16 PIN 12V - 2 x 6 | 600 |
| SATA | 2 x 400/150/150 |
| MOLEX | 400/150/150 |
| Характеристики | Да |
| ATX12V Version | ATX 12V 3.1 |
| Efficiency | 80Plus Gold |
| Dimension (DxWxH) | 150 mm x 150 mm x 85 mm |
| PFC | Active PFC (0.9) |
| Fan | 135mm FDB fan |
| Security | AFC (Automatic Fan Speed Control) · OPP (Overload Protection) · OTP (Over Temperature Protection) · OVP (Overvoltage Protection) · SCP (Short-Circuit Protection) · SIP (Surge & Inrush Protection) · UVP (Under Voltage Protection) · OCP (Over-Current Protection) |
