WiFi реле за DIN шина Shelly Pro 3EM 3CT 63
Shelly Pro 3EM 3CT 63
Commercial Building Energy ManagementFor large commercial buildings, Shelly Pro 3EM-3CT63 can monitor energy usage across various floors or departments. This allows facility managers to allocate energy costs more accurately, identify energy wastage, and implement strategies to improve overall energy efficiency.
Factory Energy Monitoring and OptimizationIn a manufacturing plant, Shelly Pro 3EM-3CT63 can be used to monitor the energy consumption of heavy machinery across different phases. By tracking real-time usage, you can identify inefficiencies and reduce operational costs by optimizing energy usage during peak and off-peak hours.
Store Energy ManagementIf you are store owner, you can use Shelly Pro 3EM-3CT63 to monitor the energy consumption of key systems like lighting, HVAC, and refrigeration units. By tracking the power usage of these systems in real-time, store owners can identify when and where energy is being wasted—such as leaving lights on after hours or running HVAC systems inefficiently. This allows for better control over operating costs, helps in reducing energy bills, and supports sustainable business practices by lowering overall energy consumption.
Electric Vehicle (EV) Charging MonitoringMonitor the energy consumption of your electric vehicle charger in real-time. Shelly Pro 3EM with the 3-phase current transformer (3CT63) can track how much power your EV charger uses, helping you manage and optimize energy consumption, ensuring that your home stays within its energy budget.
Solar Power ManagementIf your home is equipped with solar panels, Shelly Pro 3EM-3CT63 can measure the energy generated by your solar system, as well as the energy consumed from the grid. This helps in optimizing energy usage, ensuring that you maximize the use of solar energy and reduce dependency on grid power.
Whole-Home Energy MonitoringUse Shelly Pro 3EM-3CT63 to monitor the energy usage across your entire home. By tracking consumption across all three phases, you can identify which appliances or systems are using the most power, allowing you to make informed decisions to reduce energy costs and improve efficiency.
Professional Smart Meter
Shelly Pro 3EM-3CT63 reports accumulated energy as well as instantaneous voltage, current, active, and apparent power per phase/channel in real time. It stores data in non-volatile memory that can be retrieved for a period of up to 60 days in 1-minute intervals. It has a real-time clock to keep the correct time if the connection to an SNTP server is lost.
LAN, Wi-Fi, and Bluetooth connectivity
LAN connection for high security and reliability. Simultaneous Wi-Fi and LAN usage, as backup when needed.
4-quadrant measurement
Measure capacitive and inductive load types of active imported and exported energies.
Accuracy class B (active energy)
Shelly Pro EM-50 has a measurement accuracy of 1%.
Energy measurement
Monitors mono-phase electrical systems with up to 3 points simultaneously. Fast notifications and at least 60 days of 1-minute records storage.
MODBUS support
Allows for easy and fast deployment in existing industrial installations.
Scripting functionalities
Shelly Pro 3PM fully supports mjS scripting, allowing you to create further features and functionalities.
Характеристики
| Ambient working temperature | -20°C to 40°C / -5°F to 105°F |
| Влажност | 30% to 70% RH |
| Max. altitude | 2000 m / 6562 ft |
| Screw terminals max torque | 0.4 Nm / 3.5 lbin |
| Conductor cross section | Shelly Pro 3EM-3CT63: 0.5 to 2.5 mm² / 20 to 14 AWGShelly 3CT63: 0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length | 6 to 7 mm / 0.24 to 0.28 in |
| Монтаж | Shelly Pro 3EM-3CT63: DIN railShelly 3CT63: Freestanding on phase wires |
| Conductor aperture Shelly 3CT63 | Ø9 mm / Ø0.35 in |
| Shell material | Пластмаса |
| Electrical | Да |
| Захранване | 100-260 V~ 50/60 Hz |
| Консумация на енергия | Sensors, meters Internal-temperature sensor:Yes Voltmeter (AC):100 - 260 V Voltmeter accuracy:±1 % Ammeter (AC):0 - 63 A Ammeter accuracy:±1 % (2 - 63 A), ±2 % (1 - 2 A), ±5 % (0 - 1 A) Compatible current transformers:3CT63 Power and energy meters:Active and apparent powerActive and apparent energyPower factorFundamental active and fundamental reactive energy Channel-to-channel calibration minimum load:500 W per channel No load threshold:30 VA per channel Measurement data storage:At least 60 days of 1 min data resolution Data export:CSV for PQ recorded valuesJSON format export through RPC Radio Wi-Fi Protocol:802.11 b/g/n RF band:2400 - 2495 МHz |
| Max. RF power | Bluetooth Protocol:4.2 RF band:2400 - 2483.5 MHz |
| Max. RF power | Microcontroller unit CPU:ESP32-D0WDQ6 Flash:16 MB Firmware capabilities Webhooks (URL actions):20 with 5 URLs per hook Scripting:Yes MQTT:Yes Scripting:Yes Encryption:Yes |
