Shelly EM Mini Gen4
Power consumption analysis for cost optimization
All connected electrical appliances we don't use during the night or forgotten switched-on lights generate unnecessary energy. Shelly EM Mini Gen4's smart energy metering will help you identify and eliminate any redundant energy consumption from each connected appliance around your home or facility. Together with smart scenes, you can use Shelly EM Mini Gen4's data to trigger scenarios, such as turning off appliances during a spike to protect them or during the night to save energy. *
*This is only an energy meter. There is no relay inside.
Preventative monitoring
When an electrical appliance is damaged, it doesn't simply stop working. Usually, it increases the amount of energy used in an attempt to compensate for its operational capacity. Since there is no visible difference in its performance, it might take months before you can identify a problem, leading to inefficiency and wasted energy. Shelly EM Mini Gen4 will fit anywhere you need it to and can immediately report the increase in energy consumption, saving you additional expenses on repairs or equipment replacement.
Multiprotocol connectivity
Highly compatible! Choose the best protocol for your smart home—Zigbee, Wi-Fi, or Bluetooth
Energy Metering
Provides precise monitoring of the energy consumption of the connected appliance or device
Smart scenes
Set custom scenes by combining Shelly EM Mini Gen4 with your other devices
Matter certified
Integrates into any Matter ecosystem
Smart schedules
Set custom schedules based on your daily agenda
Scripting
Shelly EM Mini Gen4 fully supports mjS scripting, allowing you to create custom features and functionalities
Характеристики
| Ambient working temperature | -20 °C to 40 °C / -5 °F to 105 °F |
| Влажност | 30 % to 70 % RH |
| Max. altitude | 2000 m / 6562 ft |
| Screw terminals max torque | 0.4 Nm / 3.5 lbin |
| Conductor cross section | 0.5 to 4 mm² / 20 to 11 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length | 6 to 7 mm / 0.24 to 0.28 in |
| Монтаж | Wall console |
| Shell material | Пластмаса |
| Electrical | Да |
| Захранване | 110-240 V~ |
| Консумация на енергия | Sensors, meters Voltmeter (AC):110-240 V~ 50/60 Hz Voltmeter accuracy:±1% Ammeter (AC):0 - 16A Ammeter accuracy:±1% Power and energy meters:Active powerActive energy Measurement data storage:At least 10 days of 1 min data resolution Data export:CSV for PQ recorded valuesJSON format export through RPC Output circuits ratings Power measurement:Yes Max. measurement voltage:240 V~ Max. measurement current:16 A Max. measurement power:3840 W Radio Wi-Fi Protocol:802.11 b/g/n/ax RF band:2412 - 2472 МHz |
| Max. RF power | Bluetooth Protocol:5.0 RF band:2402 - 2480 MHz |
| Max. RF power | Zigbee Protocol:802.15.4 RF bands:2400 to 2483.5 MHz |
| Max. RF power | Microcontroller unit CPU:ESP-Shelly-C68F Flash:8MB Firmware capabilities Schedules:20 Webhooks (URL actions):20 with 5 URLs per hook Scripting:Yes MQTT:Yes UDP:Yes Advanced schedules:Yes KVS (Key-Value Store):Yes |
