Shelly
Wi-Fi реле Shelly Plus 0-10V
Артикул №: 1000060244
Категория:
Смарт автоматизация
19,99 €
✓ Налично в централен склад
Wi-Fi operated
Connect Shelly Plus 0-10V Dimmer to your Wi-Fi network. No HUB required!
Smart schedules
Set custom schedules based on your daily agenda, or follow the sunrise/sunset and control your lighting accordingly.
Smart scenes
Set custom scenes by combining Shelly Plus 0–10V Dimmer with your other Shelly devices.
Bluetooth
Quick inclusion via Bluetooth or use it as a Bluetooth gateway.
Flexible input control
Use it with your existing switches, no matter if they're single or dual button.
Scripting
Shelly Plus 0-10V Dimmer fully supports scripting, allowing you local control and custom functionalities.
Характеристики
| Size (HxWxD) | 42x37x17 ±0.5 mm / 1.65x1.46x0.66 ±0.02 in |
| Тегло | 17 g / 0.60 oz |
| Screw terminals max torque | 0.4 Nm / 3.5 lbin |
| Conductor cross section | 0.5 to 1.5 mm² / 20 to 16 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length | 5 to 6 mm / 0.20 to 0.24 in |
| Монтаж | In-wall |
| Shell material | Plastic |
| Shell color | Shell: 2716C, print: black Environmental |
| Ambient working temperature | -20 °C to 40 °C / -5 °F to 105 °F |
| Влажност | 30 % to 70 % RH |
| Max. altitude | 2000 m / 6562 ft Electrical |
| Захранване | 110 - 240 VAC ±10% |
| Консумация на енергия | Output circuits ratings |
| Max. switching voltage | 10 VDC |
| Max. switching power | 0.35 W |
| Max. switching current | 35 mA Sensors, meters |
| Internal-temperature sensor | Yes Wi-Fi |
| Protocol | 802.11 b/g/n |
| RF band | 2401 - 2495 МHz |
| Max. RF power | Bluetooth |
| Protocol | 4.2 |
| RF band | 2400 - 2483.5 MHz |
| Max. RF power | Microcontroller unit |
| CPU | ESP32-U4WDH |
| Flash | 4 MB Firmware capabilities |
| Schedules | 20 |
| Webhooks (URL actions) | 20 with 5 URLs per hook |
| MQTT | Да |
| Scripting | Да |
