Водно охлаждане за процесор HYTE THICC Q60

HYTE THICC Q60
FAN-HYTE-Q60-BW

Specs:
Weight 2.31 kg
CPU Compatibility Intel Socket LGA 1700, 1200, 115X - AMD Socket AM5, AM4
Heat Exchanger Dimensions 120 x 288 x 52 mm
Heat Exchanger Material Aluminum
Heat Exchanger Technology Parallel Dual Pass
Cold Plate Dimensions 56 x 56 x 1.5 mm
Cold Plate Material Copper
Cold Plate Technology Micro-Skived Fin
Magnetic Interchangeable Cold Plate Cover Anodized Aluminum
Tube Length 400 mm
Tube Material CIIR Rubber with Nylon Sleeving
Total CPU Block + LCD Screen Height 105 mm
Fans THICC FP12 x 2
Fan Dimensions 120 x 120 x 32 mm
Fan Speed 0 – 3,000 RPM
Air Flow 105.8 CFM
Static Pressure 8.14 mm-H2O
Noise Level <10.0 - 47.3 dBA
Bearings Fluid Dynamic Bearing
Fan Blade Material Fiberglass Reinforced Liquid Crystal Polymer (LCP)
Fan Frame Material Polycarbonate
Fan Connector Nexus Link Type-M
Nexus-Link Channels 1x Type-C, 1x Type-M
Maximum Devices – Single Channel 18
Maximum Devices – All Channels 34
Maximum Current – Single Channel 8A/12V
Maximum Current – All Channels 15A/12V
Maximum PSU Power Draw Up to 180W depending on the number of connected Nexus Link devices
LCD Size 5 Inches
LCD Mounting Orientation Portrait
Resolution 720 x 1280 (293 PPI)
LCD Panel Type IPS
LCD Hinge Double-Hinged Floating Spout
LCD Refresh Rate 60 Hz
LCD Brightness 300 nits
Bias Lighting 42-Pixel qRGB Array
Logo Lighting 4-Pixel qRGB Array
Pump RPM 2,000 – 4,500 RPM
Pump Bearing Ceramic
Pump Impeller Diameter 24 mm
Coolant Operation Temperatures -10 to 60 C
Processor Quad-Core 64-bit ARM Cortex
Speed 1.3 GHz
RAM 2GB DDR4@2666MT/s
Storage 32GB eMMC
Graphics Engine 500 MHz
Co-Processor 32-Bit ARM Cortex-M4
Input Connections USB 2.0 Header, PWM, 6-Pin PCIe Power
Thermal Paste Yes, Pre-Applied
Nexus Powered Yes

JAR Computers може да предложи /смяна/монтаж в наш сервиз или при .
