Вентилатор 120mm
Efficient Performance at High Air Resistance
Thanks to high static pressure, the Pro fans move air effectively through tight spaces. This makes them ideal for radiators, perforated panels, and mesh filters.
Maximum Performance, Redefined
Revised fan blade design for an optimal balance of performance and smooth operat
Optimized Bearing-Shaft Design (DBB)
A dual ball bearing with an extended rotor shaft ensures high durability and maximum lifespan at high rotational speeds.
Automated Balancing
An automated measuring and balancing process ensures exceptional precision and smooth performance by applying the balancing compound with pinpoint accuracy.
Minimum Gap Dimensions for Maximum Efficiency
Enables higher static pressure and maximum airflow efficiency.
Характеристики
| Dimensions (L x W x H)120 x 120 | x 25 mm |
| Net Weight185 g | Да |
| Fan Speed600 – | 3000 rpm (PWM controlled) |
| Fan Speed Below | 5% PWM0 rpm |
| Airflow77 cfm / | 131 m³/h |
| Static Pressure6.9 mmH₂O | Да |
| Fan BearingDual Ball Bearing | Да |
| Typical Voltage12 V DC | Да |
| Start Up Voltage3.3 V DC | Да |
| Current0.33 A | Да |
| Cable Length400 mm + | 80 mm Daisy-Chain |
| Connector4-Pin Fan Plug + | 4-Pin Socket |
| Packaging Width125 mm | Да |
| Packaging Height30 mm | Да |
| Packaging Length127 mm | Да |
| Packaging Weight0.226 kg | Да |
