APC EASY UPS BV 800VA, AVR, IEC Outlet, 230V
Technical Specifications
Output
Output power capacity
450Watts / 800VA
Max Configurable Power (Watts)
450Watts / 800VA
Nominal Output Voltage
230V
Output Frequency (not synced)
50/60 Hz +/-1 Hz
Topology
Line Interactive
Waveform type
Stepped approximation to a sinewave
Output Connections
(6) IEC 320 C13 (Battery Backup)
Transfer Time
6ms typical : 10ms maximum
Input
Nominal Input Voltage
230V
Input frequency
50/60 Hz +/- 5 Hz (auto sensing)
Input Connections
IEC-320 C14
Cord Length
1.52meters
Number of Power Cords
1
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Expected Battery Life (years)
3 - 5
Efficiency
View Efficiency Graph
Communications & Management
Control panel
LED Status display with On Line : On Battery
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Physical
Maximum Height
92mm, 9.25CM
Maximum Width
160mm, 16.05CM
Maximum Depth
305mm, 30.5CM
Net Weight
5.3KG
Shipping weight
5.6KG
Shipping Height
237mm, 23.7CM
Shipping Width
143mm, 14.3CM
Shipping Depth
373mm, 37.3CM
Environmental
Operating Temperature
0 - 40 °C
Operating Relative Humidity
0 - 90 %
Operating Elevation
0-1968.3meters
Audible noise at 1 meter from surface of unit
40.0dBA
Conformance
Approvals
CE
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
