| Max Configurable Power (Watts) |
520Watts / 850VA |
| Output Frequency (sync to mains) |
47 - 63 Hz |
| Output Frequency |
220 Hz |
| Topology |
Standby |
| Waveform type |
Stepped approximation to a sinewave |
| Transfer Time |
6ms typical : 10ms maximum |
| Input |
Да |
| Input frequency |
47 - 63 Hz |
| Input voltage range for main operations |
220 |
| Batteries & Runtime |
Да |
| Тип батерия |
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
| Battery Charge Power (Watts) |
6kWatts |
| Battery Volt-Amp-Hour Capacity |
93 |
| Communications & Management |
Да |
| Interface Port(s) |
USB |
| Control panel |
LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators, LED status display with On Line : On Battery : Replace Battery and Overload indicators |
| Audible Alarm |
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Surge Protection and Filtering |
Да |
| Surge energy rating |
310JoulesControl panel |
| LED status display with On Line |
On Battery : Replace Battery and Overload indicators |
| Physical |
Да |
| Maximum Height |
120MM, 12.0CM |
| Maximum Width |
130MM, 13.0CM |
| Maximum Depth |
365MM, 36.5CM |
| Нето тегло |
4.5KG |
| Shipping weight |
5.0KG |
| Shipping Height |
190MM, 19.0CM |
| Shipping Width |
186MM, 18.6CM |
| Shipping Depth |
441MM, 44.1CM |
| Цвят |
Черен |
| Master Carton Weight |
16.0 |
| Environmental |
Да |
| Работна температура |
0 - 40 °C |
| Operating Relative Humidity |
0 - 90 % |
| Operating Elevation |
0-900meters |
| Температура на съхранение |
-15 - 45 °C |
| Storage Relative Humidity |
0 - 95 % |
| Storage Elevation |
0-4500meters |
| Audible noise at 1 meter from surface of unit |
45.0dBA |
