| Apparent Power Output |
3000 V·A |
| Battery Chemical Composition |
Lead-Acid |
| Battery Runtime |
5.5 minute [unit of time] |
| Тип батерия |
Portable |
| Battery Weight |
2.5 kg |
| CN8 |
85044000 |
| Communication Interface |
USB, RS-232 |
| Communication Protocol and Connection |
SNMP |
| Connection Type |
IEC C20 |
| Държава на произход |
China (CN) |
| Customs Tariff Number |
85044000 |
| Data Sheet, Technical Information |
4NWD003883 |
| Declaration of Conformity - CE |
4NWD003869 |
| E-Number (Sweden) |
5257249 |
| EAN |
7640169261923 |
| ETIM 6 |
EC000382 - UPS |
| ETIM 7 |
EC000382 - UPS |
| Efficiency |
Overall 91.00 % |
| Economy Mode (Eco-Mode) |
98.00 % |
| Environmental Information |
No declaration needed |
| Harmonic Distortion |
5.00 % |
| Input Voltage (Uin) |
220 V |
| 230 V |
Да |
| 240 V |
Да |
| Input Voltage Type |
AC |
| Instructions and Manuals |
4NWD003883 |
| Invoice Description |
UPS PowerValue 11 T G2 3 kVA B |
| Minimum Order Quantity |
1 piece |
| Number of Outputs |
C13 Connection 4 |
| C19 Connection |
1 |
| Number of Phases |
Primary - 1 |
| Secondary - |
1 |
| Object Classification Code |
G |
| Options Provided |
Auto shut down function |
| Potential free switch contact |
Да |
| Network-management |
Да |
| Output Voltage (Uout) |
208 V |
| 220 V |
Да |
| 230 V |
Да |
| 240 V |
Да |
| Package Level 1 Depth / Length |
500 mm |
| Package Level 1 EAN |
7640169261923 |
| Package Level 1 Gross Weight |
24.6 kg |
| Package Level 1 Height |
464 mm |
| Package Level 1 Units |
1 piece |
| Package Level 1 Width |
324 mm |
| Power Factor |
0.9 |
| Product Main Type |
PowerValue 11T G2 |
| Product Name |
UPS |
| Product Net Depth / Length |
399 mm |
| Product Net Height |
327 mm |
| Product Net Weight |
22.2 kg |
| Product Net Width |
190 mm |
| Rated Frequency (f) |
Primary 50 Hz |
| Primary |
60 Hz |
| Secondary |
50 Hz |
| Secondary |
60 Hz |
| Rated Output Power |
2700 W |
| RoHS Date |
0318 |
| RoHS Information |
4NWD003869 |
| RoHS Status |
Following EU Directive 2011/65/EU |
| Selling Unit of Measure |
piece |
| Uninterruptible Power Supply Form Factor |
Tower |
| Uninterruptible Power Supply Topology |
On-Line Double Conversion |
| WEEE B2C / B2B |
Business To Business |
| WEEE Category |
5. Small Equipment (No External Dimension More Than 50 cm) |
| Number of Batteries |
4 |
