Точка за достъп ZyXEL NWA90AXPRO
ZyXEL NWA90AXPRO
Multi-gig WiFi 6 access point for small businesses
AX3000 Dual-Radio Multi-gig PoE Access Point with secure authentication support
Multi-gig WiFi 6 access point for small businesses Delivering AX3000 WiFi speed with 2.5G Ethernet uplink port, the Zyxel NWA90AX Pro provides the powerful and fastest WiFi 6 speed for small businesses, SoHo, and home offices. Small business owners looking for an affordable WiFi 6 access point with multi-gig connectivity, Zyxel’s NWA90AX Pro is no doubt the ideal choice for them to support more connected devices and applications with the fastest speeds.
5Ghz extended range for small biz AX3000 (3x3:2 in 5Ghz; 2x2:2 in 2.4Ghz) AP provides maximum data rate of 3000 Mbps, and the 2.5G uplink port enables multi-gig connectivity for small biz networks Multi-gig WiFi with connection stabilization design Obtain the multi-gigabit performance with a 2.5Gbps PoE port to support the most demanding wireless requirements The Multi-gig Connection Stabilization Pad secures the connection between the Cat 5E cable and the RJ45 connector to ensure the 2.5G speed is linked for maximum throughput.
Boost your WiFi performance To better leverage the faster speeds in 5Ghz band, Zyxel NWA90AX Pro equips with 3x high-gain antennas to boost WiFi signals and extend coverage, especially to previously hard-to-reach areas. In addition to the WiFi boost, NWA90AX Pro also comes with the premium multi-gig Ethernet connections. As it can run on the common-type Cat5e cabling, a 2.5G uplink port breaks through the 1.0G bottleneck without re-cabling, making it easy to create an affordable high-speed network environment for your business or home.
Secure authentication to protect business networks
With the support of captive portal and IEEE802.1x authentication, the NWA90AX Pro not only offers small business users the enterprise-level security to protect their networks, but also the flexible opportunity to customize wireless network usage login for marketing and business recognition.
Характеристики
| Standard | Да |
| IEEE802.11 ax/ac/n/g/b/a | Да |
| MIMO | Да |
| MU-MIMO | Да |
| Wireless speed | Да |
| 2.4GHz | 575 Mbps |
| 5GHz | 2400 Mbps |
| Frequency band | Да |
| 2.4 GHz | USA (FCC): 2.412 to 2.462 GHz Europe (ETSI): 2.412 to 2.472 GHz |
| 5 GHz | USA (FCC): 5.15 to 5.35 GHz; 5.470 to 5.850 GHz European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz Bandwidth 20-, 40- and 80-MHz Conducted typical transmit output power*1 |
| US (2.4GHz/5GHz) | 23/28 dBm |
| EU (2.4GHz/5GHz) | 20/28 dBm RF Design Antenna type 3x3 + 2x2 MIMO Embedded Antenna Antenna gain 2.4GHz: 3 dBi 5GHz: 4 dBi Minimum receive sensitivity Min. Rx sensitivity up to -99 dBm WLAN Feature Band steering Yes WDS/Mesh Yes Fast roaming Yes DCS Yes Load balancing No Security Encryption WEP WPA WPA2-PSK WPA3 Authentication WPA WPA2-Enterprise EAP IEEE 802.1X RADIUS authentication Access management L2-isolation MAC filtering Rogue AP detection Networking IPv6 Yes VLANs Yes WMM Yes U-APSD Yes Management Operating mode Nebula cloud managed Standalone ZON Utility Discovery of Zyxel switches, APs and gateways |
| Centralized and batch configurations | IP configuration IP renew Device reboot Device locating Web GUI access Firmware upgrade Password configuration Web UI/CLI Yes SNMP NO Physical Specifications Dimensions (WxDxH)(mm) 140 x 140 x 37.5 Weight (g) 352 MTBF (hr) 420,539 Physical Interfaces Ethernet port 1 x 1/2.5Gbps LAN Power Input: AC 100 - 240V - 50/60 Hz 0.3A; Output: DC +12V 1.5A PoE (802.3at): power draw 20.5 W PoE modes IEEE802.3af: Not supported IEEE802.3at: Unrestricted IEEE802.3bt: Unrestricted |
