Точка за достъп Ubiquiti UAP-AC-EDU

Ubiquiti UAP-AC-EDU

Dimensions
287.5 x 287.5 x 125.9 mm
(11.32 x 11.32 x 4.96")

Weight
1.820 kg (4.012 lb)

Networking Interface
Dual‑Band Wi‑Fi / Gigabit Ethernet

Ports
(2) 10/100/1000 Ethernet Ports
(1) USB 2.0 Port

Buttons
Reset
Power Method
Passive Power over Ethernet (48V), 803.2at Supported
(Supported Voltage Range: 44 to 57VDC)

Power Supply
48V, 0.5A PoE Gigabit Adapter*
Power Save
Supported

Maximum Power Consumption
20W

Maximum TX Power
2.4 GHz 22 dBm
5 GHz 22 dBm
Antennas
(3) Dual‑Band Antennas, 2.4 GHz: 3 dBi, 5 GHz: 3 dBi
Wi-Fi Standards
802.11 a/b/g/n/ac
Wireless Security
WEP, WPA
‑
PSK, WPA
‑
Enterprise (WPA/WPA2, TKIP/AES)

BSSID
Up to Four per Radio

Mounting
Wall/Ceiling (Kits Included)

Operating Temperature
‑
10 to 70° C (14 to 158° F)

Operating Humidity
5 to 95% Noncondensing

Certifications
CE, FCC, IC
*
Only the single
‑
pack of the UAP
‑
AC
‑
EDU includes a PoE adapter.

Advanced Traffic Management
VLAN
802.1Q

Advanced QoS
Per‑User Rate Limiting Guest Traffic Isolation

Supported
WMM
Voice, Video, Best Effort, and Background

Concurrent Clients 250+

Supported Data Rates (Mbps)
Standard Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 450 Mbps (MCS0‑MCS23, HT 20/40)
802.11ac 6.5 Mbps to 1300 Mbps (MCS0‑MCS9 NSS1/2/3, VHT 20/40/80)
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps

Loudspeaker Acoustics
Sensitivity 94 dB (1W/1 m)
Maximum SPL 103 dB @ 1 m
Frequency Response 100‑20,000 Hz
Type Two‑Way Speaker with Second‑Order HP Filter
