Точка за достъп Tenda W9

Tenda W9

Hardware
Dimension
86*86*34.8mm

Interfaces
1*10/100Mbps PoE Data Input LAN
1*10/100Mbps Data Output LAN

Button
1*Reset Button

Antenna
4*4dBi

Maximum Power Consumption
3.8W

LED Indicator
SYS and LAN
Power Supply
PoE 802.3af

Wireless
Frequency Range
2.4GHz and 5GHz dual band

Maximum wireless speed
2.4GHz:300Mbps
5GHz:867Mbps

Standard&Protocol
IEEE 802.11b/g/n/ac(wave2)

Reception Sensitivity
2.4GHz MCS0 -92dBm
2.4GHz MCS7 -72dBm
5GHz 6Mbps -92dBm
5GHz MCS7 -72dBm
5GHz MCS9 -64dBm

Software
MU-MIMO
Support

Operating Mode
AP/Client AP

Max. No. of SSID
2.4GHz:8
5GHz: 4
Hide SSID
Support
WEP

Support
WPA-PSK

Support
WPA2-PSK

Support
WPA

Support
WPA2

Support
Access control

Support
Adjustable power transmit

Support
AP isolation

Support
Connected clients control

Support
RSSI Threshold

Support
WMM

Support
VLAN tagging for SSID

Support
LED control

Support
Diagnostics

Support
Schedule Reboot

Support
Reboot at specified interval

Support
System Logs

Support
Firmware upgrade

Support
Reboot

Support
Reset Button

Support
Backup configuration

Support
Restore configuration

Support
Centralized Management
M3 or Tenda Router with AP Controller feature

Others
Operation Temperature
-10℃ ~ 45℃

Storage Temperature
-30℃ ~ 70℃

Operating Humidity
10%~90% non-condensing

Storage Humidity
10%~90% non-condensing

Default login IP
192.168.0.254

Certification
CE、RoHS
