HARDWARE FEATURES
Standards and Protocols
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab,
IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s,
IEEE 802.1w, IEEE 802.1q, IEEE 802.1p
Interface
8 10/100/1000Mbps RJ45 Ports
(Auto-Negotiation/Auto MDI/MDIX)
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e or above cable
(maximum 100m)
Standards and Protocols
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab,
IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s,
IEEE 802.1w, IEEE 802.1q, IEEE 802.1p
Interface
8 10/100/1000Mbps RJ45 Ports
(Auto-Negotiation/Auto MDI/MDIX)
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e or above cable
(maximum 100m)
Технически характеристики
| 10BASE-T | UTP category 3, 4, 5 cable (maximum 100m) |
| 100BASE-TX/1000Base-T | UTP category 5, 5e or above cable |
| Dimensions (W X D X H) | 8.2* 4.9* 1.0 in. (209* 126* 26mm) |
| Fan Quantity | Fanless |
| Консумация на енергия | Maximum: 6.42W (220V/50Hz) |
| Захранване | 100~240VAC, 50/60Hz |
| Bandwidth/Backplane | 16Gbps |
| MAC Address Table | 8k |
| Packet Forwarding Rate | 11.9Mpps |
| Jumbo Frame | 9216 Bytes |
| Queue scheduling | SP, WRR, SP+WRR |
| Time Setting | SNTP |
| Firmware Upgrade | TFTP & Web |
| System Diagnose | VCT |
| Работна температура | 0℃~40℃ (32℉~104℉); |
| Температура на съхранение | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
