TP-Link
Суич TP-Link Omada SG2428LP
Артикул №: 1000137155
Категория:
Мрежови адаптери
315,99 €
✓ Налично във външен склад
Omada 28-Port Gigabit Smart Switch with 16-Port PoE+
| 16× Gigabit 802.3af/at PoE+ ports | Да |
| 8× Gigabit non-PoE RJ45 ports and 4× Gigabit SFP slots | Да |
| W total PoE budget with up to 30 W PoE output per port* | 150 |
| Centralized cloud management via the web or the Omada app† | Да |
| Standalone management via web, CLI, SNMP, and RMON | Да |
| VLAN, ACL, QoS, and IGMP Snooping | Да |
| Fanless design for quiet operation | Да |
| Durable metal casing and rackmountable design | Да |
| HARDWARE FEATURES | Interface: • 16× 10/100/1000 Mbps PoE+ RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) · • 8× 10/100/1000 Mbps non-PoE RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) · • 4× Gigabit SFP Slots · Fan Quantity: Fanless Physical Security Lock: √ Power Supply: 100-240V AC, 50/60Hz PoE Ports (RJ45): • Standard: 802.3at/af compliant · • PoE+ Ports: 16 Ports (up to 30 W PoE Output per Port) · • PoE Power Budget: 150 W* Dimensions ( W x D x H ): 17.3×8.7×1.73 in (440×220×44 mm) Mounting: Rack Mountable Max Power Consumption: 184.7 W (110V/60Hz) (with 150 W PD connected) Max Heat Dissipation: 628.0 BTU/hr (110V/60 Hz) (with 150 W PD connected) |
| PERFORMANCE | Switching Capacity: 56 Gbps Packet Forwarding Rate: 41.66 Mpps MAC Address Table: 8K Packet Buffer Memory: 4.1 Mbit Jumbo Frame: 9 KB |
| SOFTWARE FEATURES | Quality of Service: • 802.1p CoS/DSCP priority · • 8 priority queues · • Priority Schedule Mode: SP (Strict Priority), WRR (Weighted Round Robin) · • Queue Weight Config · • Bandwidth Control: Port/Flow-based Rating Limit · • Smoother Performance · • Storm Control: Multiple Control Modes(kbps/ratio), Broadcast/Multicast/Unknown-Unicast Control L2 and L2+ Features: • 16 IP Interfaces: Support IPv4/IPv6 Interface · • Static Routing: 32 IPv4/IPv6 Static Routes · • DHCP Server · • DHCP Relay · - DHCP Interface Relay · - DHCP VLAN Relay · • DHCP L2 Relay · • Static ARP · • Proxy ARP · • Gratuitous ARP · • Link Aggregation · • Spanning Tree Protocol · • Loopback Detection · • 802.3x Flow Control · • Mirroring · • Device Link Detect Protocol (DLDP) · • 802.1ab LLDP/ LLDP-MED L2 Multicast: • 511 IPv4, IPv6 shared multicast groups · • IGMP Snooping · • Multicast VLAN Registration (MVR) · • Multicast Filtering · • Limited IP Multicast (256 profiles and 16 entries per profile) Advanced Features: • Automatic Device Discovery† · • Batch Configuration† · • Batch Firmware Upgrading† · • Intelligent Network Monitoring† · • Abnormal Event Warnings† · • Unified Configuration† · • Reboot Schedule† VLAN: • VLAN Group: Max. 4K VLAN Groups · • 802.1Q tag VLAN · • MAC VLAN: 12 Entries · • Protocol VLAN · • GVRP · • Voice VLAN Access Control List: • Support up to 230 entries · • Time-based ACL · • MAC ACL · • IP ACL · • IPv6 ACL · • Combined ACL · • Rule Operation: Permit/Deny · • Policy Action · - Mirroring · - Redirect · - Rate Limit · - QoS Remark · • ACL Rules Binding · - Port Binding · - VLAN Binding Security: • IP-MAC-Port Binding · • AAA · • 802.1X · - Port based authentication · - MAC (Host) based authentication · - Authentication Method includes PAP/EAP-MD5 · - MAB · - Guest VLAN · - Radius authentication and accountability support · • IP/IPv6-MAC Binding · - 512 Binding Entries · - DHCP Snooping · - DHCPv6 Snooping · - ARP Inspection · - ND Detection · • IP Source Guard · - 253 Entries · - Source IP+Source MAC · • IPv6 Source Guard · - 183 Entries · - Source IPv6 Address+Source MAC · • DoS Defend · • Static/Dynamic/Permanent Port Security: Up to 64 MAC addresses per port · • Broadcast/Multicast/Unicast Storm Control: kbps/ratio control mode · • Port Isolation · • Secure web management through HTTPS with SSLv3/TLS 1.2 · • Secure Command Line Interface (CLI) management with SSHv1/SSHv2 · • IP/Port/MAC-based access control IPv6: • IPv6 Static Routing and ACL · • IPv6 Dual IPv4/IPv6 · • IPv6 Interface · • Multicast Listener Discovery (MLD) Snooping · • IPv6 neighbor discovery (ND) · • Path maximum transmission unit (MTU) discovery · • Internet Control Message Protocol (ICMP) version 6 · • TCPv6/UDPv6 · • IPv6 applications: DHCPv6 Client, Ping6, Tracert6, Telnet(v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP MIBs: • MIB II (RFC1213) · • Bridge MIB (RFC1493) · • P/Q-Bridge MIB (RFC2674) · • Radius Accounting Client MIB (RFC2620) · • Radius Authentication Client MIB (RFC2618) · • Remote Ping, Traceroute MIB (RFC2925) · • Support TP-Link private MIBs · • RMON MIB(RFC1757, rmon 1,2,3,9) |
| MANAGEMENT | Omada App: Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Centralized Management: • Omada Cloud-Based Controller · • Omada Hardware Controller · • Omada Software Controller Cloud Access: Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Zero-Touch Provisioning: Yes. Requiring the use of Omada Cloud-Based Controller Management Features: • Web-based GUI · • Command Line Interface (CLI) through telnet · • SNMPv1/v2c/v3 · • SNMP Trap/Inform · • RMON (1,2,3,9 groups) · • SDM Template · • DHCP/BOOTP Client · • Dual Image, Dual Configuration · • CPU Monitoring · • Cable Diagnostics · • EEE · • SNTP · • System Log |
