Суич TP-Link LiteWave LS109P

TP-Link LS109P

• 63 W PoE Budget : Eight 10/100 Mbps 802.3af/at-compliant PoE ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.
• Up to 250 m PoE Transmission : With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.
• PoE Auto Recovery : Automatically reboots your dropped or unresponsive PoE-powered devices.
• Traffic Separation for Higher Security : Isolation Mode allows one-click client traffic separation to avoid snooping and tampering, and isolate broadcast storms.
• Plug and Play : Simply plug and play for instant connectivity with no configuration required.
• Silent Operation : Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses.
• Reliable Hardware Design : Durable metal casing and desktop/wall-mounting design are well-suited for different environments.

Specs:

HARDWARE FEATURES

Interface• 9× 10/100 Mbps RJ45 Ports (8× 10/100 Mbps 802.3af/at PoE+ Ports) • AUTO Negotiation • AUTO MDI/MDIX

Network Media• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m)

Fan QuantityFanless

Installation• Desktop • Wall Mounting

Power SupplyExternal Power Adapter (Output: 53.5VDC / 1.31A)

PoE Ports (RJ45)• Standard: 802.3 af/at compliant • PoE Ports: Ports 1–8, up to 30 W PoE output per port • Power Supply: 63 W

LED Indicator• Power • Link/Act • PoE Status • PoE MAX

Dimensions ( W x D x H )171×98×27 mm

Max Power Consumption• 3.67 W (220 V/50 Hz no PD connected) • 73.24 W (220 V/50 Hz with 63 W PD connected)

Max Heat Dissipation• 12.48 BTU/h (220 V/50 Hz no PD connected) • 249 BTU/h (220 V/50 Hz with 63 W PD connected)
