Ruijie
Суич Ruijie RG-NBS3300-16MG4XS-HP
Артикул №: 1000138373
Категория:
Мрежови адаптери
571,99 €
✓ Налично във външен склад
Ruijie RG-NBS3300-16MG4XS-HP
Highlight Features
- 2.5 Gbps ports smash the gigabit barrier and unlock the full potential of Wi-Fi 6/7 APs
- 802.3bt/at/af-compliant PoE++ ports with a total power supply of 370 W
- CPP protects the CPU from attacks, ensuring CPU performance and stability
- Enterprise-grade quality ensures high performance
- Multiple security policies protect your network
- Easy Cloud Management Anytime and Anywhere
Характеристики
| SpecificationRG-NBS3300-16MG4XS-HP | Да |
| Number of | 10/100/1000/2500BASE-T Ports16 |
| Number of | 10 Gbps Optical Ports (SFP+)4 |
| Number of PoE/PoE+ Ports12 | Да |
| Number of PoE/PoE+/PoE++ Ports4 | Да |
| Number of Fans2 | Да |
| Power Supply OptionsSingle fixed power supply | Да |
| Forwarding Rate119.04 Mpps | Да |
| Switching Capacity160 Gbps | Да |
| MAC Address Table Size16000 | Да |
| ARP Table Size1000 | Да |
| Number of ACEsInbound | 1900 Outbound: 0 |
| Power SupplyRated voltage range | 100–240 V Maximum voltage range: 90–264 V Frequency: 50/60 Hz Rated current: 6 A |
| Power ConsumptionNo PoE load | Max. PoE Power Budget370 W Output Power54 V/7.6 A, P = 409 W AirflowLeft to back Operating Temperature0°C to 50°C (32°F to 122°F) Storage Temperature–40°C to +70°C (–40°F to +158°F) Operating Humidity10% to 90% RH (non-condensing) Storage Humidity5% to 95% RH (non-condensing) Port Surge ProtectionCommon mode: 6 kV Power Supply Surge ProtectionCommon mode: 6 kV Differential mode: 6 kV Net Weight3.6 kg (7.94 lbs) Gross Weight5.24 kg (11.55 lbs) CertificationCE; FCC Software Specifications Software SpecificationsRG-NBS3300-16MG4XS-HP MulticastIGMPIGMP Filtering IGMP Fast Leave ACL and QoSACLIP Standard ACL MAC Extended ACL IP Extended ACL IPv6 ACL QoSPort-Level Rate Limiting (Ingress/Egress) Security802.1XIEEE 802.1X Authentication Port-based Authentication MAC-based Authentication Global IEEE 802.1X Authentication Control Force Authorized Force Unauthorized Port-based Single-Host Mode PEAP Authentication for Windows 7/8/10/11 Clients PEAP Authentication for macOS Clients PEAP Authentication for Linux OS Clients Management via Web InterfaceWeb Authentication HTTP HTTPS IP-MAC-Port BindingIP-MAC-Port Binding ARP Anti-SpoofingARP Anti-Spoofing IP Source GuardIP Source Guard CPU Protection Policy (CPP)Hardware CPP ReliabilityRLDPRLDP NMS and MaintenanceSPANSPAN NTP NTP Client SNMPSNMP v1 SNMP v2c SNMP v3 MQTTMQTT Self-Organizing NetworkSelf-Organizing Network Network ManagementManagement via Ruijie Cloud Ruijie CloudView Device Details on Ruijie Cloud |
