Ruijie
Суич Ruijie RG-ES209MG-P
Артикул №: 1000047077
Категория:
Суич
148,99 €
✓ Налично във външен склад
Ruijie RG-ES209MG-P
Highlight Features
- 8 x 2.5G ports and 1 x 10GE SFP+ port for higher network performance
- 8 x PoE Out ports supporting IEEE 802.3 af/at standards, 130 W PoE budget
- Aggregation of up to 4 ports, unlocking higher network speed
- Cost-effective smart cloud managed switches
- Lifetime free cloud management on Ruijie Cloud anytime, anywhere
Hardware Specifications
Port Specifications
Total number of RJ45 ports
- 8
Total number of optical ports
- 1
Number of 10GE SFP+ ports
- 1
Number of 10/100/1000/2500BASE-T ports
- 8
Power Supply and Consumption
Number of PoE Out ports
- 8
Number of PoE/PoE+ Out ports
- 8
PoE budget
- 130 W
PoE power pins
- 1–2 (+), 3–6 (-)
System Specifications
Forwarding rate
- 45 Mpps
Switching capacity
- 60 Gbps (bit/s)
Environment and Reliability
Operating temperature
- 0°C to 40°C (32°F to 104°F)
Software Specifications
Basic Configurations
PoE watchdog
- Yes
Security
Port isolation
- Yes
Характеристики
| Port Specifications | Total number of RJ45 ports |
| 8 | Total number of optical ports |
| 1 | Number of 10GE SFP+ ports |
| 1 | Number of 10/100/1000/2500BASE-T ports |
| 8 | Power Supply and Consumption |
| Number of PoE Out ports | 8 |
| Number of PoE/PoE+ Out ports | 8 |
| PoE budget | 130 W |
| PoE power pins | 1–2 (+), 3–6 (-) |
| System Specifications | Forwarding rate |
| 45 Mpps | Switching capacity |
| 60 Gbps (bit/s) | Environment and Reliability |
| Работна температура | 0°C to 40°C (32°F to 104°F) |
| Software Specifications | Basic Configurations |
| PoE watchdog | Да |
| Security | Port isolation |
