Aruba Instant On 1830

Aruba Instant On 1830 Switch Series provides an easy to use and affordable wired solution for networks supporting IT, mobile, and cloud applications.

This affordable and easy-to-deploy smart-managed switch series is ideal for small businesses looking for cost-effective wired infrastructure to keep up with evolving network demands. These entry-level, smart-managed switches offer Layer 2 switching capabilities, Gigabit connectivity, along with flexible management modes - all at an affordable price point. With a flexible management dashboard, Power over Ethernet (PoE) options, and energy-efficient features, these switches deliver a solid business network for SMBs with limited budgets.

• Smart-managed Layer 2 Ethernet switch series ready to deploy in 8, 24-, and 48-port for non-PoE and PoE models.
• Compact and fan-less 8-port PoE/ non-PoE models and 24-port non-PoE model for acoustically sensitive environments.
• Aruba Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.
• Two (2) and four (4) dedicated 1G SFP fiber ports on 24- and 48-port models respectively to eliminate traffic bottlenecks across your network.
• Option to manage your switches through local web GUI.
• Cost-effective PoE Support: With half of the ports capable of supporting PoE, these switches are ideal for the most cost-efficient environments.

Specs:

General

Device TypeSwitch - 24 ports - smart

Enclosure TypeDesktop, rack-mountable 1U

SubtypeGigabit Ethernet

Ports12 x 10/100/1000 + 12 x 10/100/1000 (PoE+) + 2 x Gigabit SFP

Power Over Ethernet (PoE)PoE+

PoE Budget195 W

PerformanceLatency (100 Mbps): 5.2 µs Latency (1 Gbps): 2.8 µs Throughput: 38.68 Mpps Switching capacity: 52 Gbps

MAC Address Table Size16000 entries

Jumbo Frame Support9216 bytes

Routing ProtocolIGMPv2, IGMP

Remote Management ProtocolSNMP 1, SNMP 2c, HTTP, HTTPS, TFTP, SCP, ICMP

Encryption AlgorithmSSL

FeaturesFlow control, auto-sensing per device, auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, firmware upgradable, SNTP support, wall mountable, Spanning Tree Protocol (STP) support, event log, Quality of Service (QoS), Trusted Platform Module (TPM), Cable Diagnostics Function, LLDP support, DHCP client, Class of Service (CoS), cloud managed, 1.5MB packet buffer, Secure Copy (SCP), Link Aggregation, dual image support, Denial of Service (DoS) protection, Energy-Efficient Ethernet (EEE), BPDU Filter, loop protection, Global Storm Control, Port Scheduling

Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ac, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az

Processor1 x ARM: 800 MHz

RAM512 MB SDRAM

Flash Memory256 MB

Status IndicatorsPort status, port duplex mode, link/activity, speed

Expansion / Connectivity

Interfaces12 x 1000Base-T RJ-45 2 x Gigabit LAN SFP 12 x 1000Base-T RJ-45 PoE+

Power

Power DeviceInternal power supply

Voltage RequiredAC 100-240 V (50/60 Hz)

Power Consumption Operational244.6 Watt
