Суич Cudy GS1028PS2 1.0
Cudy GS1028PS2 1.0
Silent Design and Heat DissipationPlug and Play, Easy of use. Fanless design for silent operation. Made of high-quality metal case, sturdy and durable with long service life, provide better heat dissipation, suitable for most environment.Pin assignmentMode A: 1/2(+),3/6(-)
High Quality PoE chipset insideEnsure High performance and stable operation of the product.Port-Power-Prioritization & Power Overload ProtectionPort-Power-Prioritization technology ensure continuous power supply of key nodes. When total power consumption exceeds maximum PoE budget, the intelligent power management will cut the lower priority port power off to ensure the high priority port's power supply and protect the device from power overload operation.Lightning protectionElectrostatic standard: contact 6KV, air 8KVMTBF > 50000 hour
Характеристики
| Interfaces | 1.25G SFP Slots · 2 |
| Gigabit RJ45 Ports · | 24 |
| Gigabit RJ45 PoE Ports · #1~#24 | Да |
| Max Power on a Single PoE Port · | 30W |
| Extend Mode Ports · #17~#24 | Да |
| VLAN Mode Ports · #1~#24 | Да |
| LED · PowerSpeed/Link/Act of Each Ethernet Port | Да |
| Performance | Max Copper Speed and Distance · Cat. 3 or higher cable: 100 meters at 10 MbpsCat. 5 or higher cable: 100 meters at 100 MbpsCat. 5e or higher cable: 100 meters at GigabitCat. 5e or higher cable: 250 meters at 10 Mbps |
| MAC Address Table · | 8192 |
| Max Switching Capacity · | 52 Gbps |
| Max Forwarding Rate · | 38.68 Mpps |
| Мощност | Power Input Type · AC Inlet |
| Power Methods · AC | Да |
| Power Input · | 100-240V~ 50/60Hz |
| Power Supply · | 300W |
| Max Power Excluding PoE · | 10W |
| Switching | 802.3 Protocols · 802.3i 10BASE-T802.3u 100BASE-TX802.3ab 1000BASE-T802.3z 1000BASE-X802.3x Flow Control802.3af PoE802.3at PoE |
| Reliability | Grounding Methods · Three-Prong Plug |
| Mechanical | Dimension · 440×204×44 mm · 17.32×8.03×1.73 inches |
| Product Weight · | 2905 g (102.47 oz.) |
| Casing Material · Metal | Да |
| Installation · DesktopRackmount via Brackets | Да |
