Рутер TP-Link Omada ER706W-4G

TP-Link Omada ER706W-4G

Omada 4G+ Cat6 AX3000 Gigabit VPN Router

• Support 4G+ Cat6: Insert a Nano SIM card to enjoy up to 300 Mbps.
• AX3000 Dual-Band WiFi 6 : Supports 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz
• 6 Gigabit Ethernet Ports : Provide high-speed wired connectivity.
• 5 High-Gain Detachable Antennas : Extend and concentrate the Wi-Fi signals.
• Centralized Management : Cloud access and the Omada app for easy management.
• Omada Mesh : Seamlessly connects to EAPs that support mesh technology.
• High-Security VPN : Supports IPSec / SSL / WireGuard / OpenVPN / PPTP / L2TP VPN.

Parameter:

4G Network TypeLTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 (2100/1800/850/2600/900/800/700/1450 MHz); LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz); 3G: B1/B3/B5/B8 (2100/1800/850/900 MHz)

Carrier AggregationB1+B1/B3/B5/B7/B8/B20/B28/B38/B40/B41; B3+B3/B5/B7/B8/B20/B28/B38/B40/B41; B5+B5/B7/B38/B40/B41; B7+B7/B8/B20/B28/B32; B8+B32/B38/B40/B41; B20+B32/B38/B40; B28+B32/B38/B40/B41; B38+B38; B40+B40; B41+B41

SIM Type1× Nano SIM Card

FrequencyDownlink: 300 Mbps; Uplink: 50 Mbps

DPIApplication control via DPI / Updated app library

IDS/IPSSignature-based IPS/IDS threat detection

Access ControlSource/Destination IP Based

FilteringWeb Group Filtering†, URL Filtering, Web Security†

ARP InspectionSending GARP Packets, ARP Scanning†, IP-MAC Binding

Attack DefenseTCP/UDP/ICMP Flood Defense; Block TCP Scan (Stealth FIN/Xmas/Null); Block Ping from WAN

Interface1× Gigabit SFP WAN/LAN; 1× Gigabit WAN; 4× Gigabit LAN/WAN

Network Media10BASE-T: Cat 3/4/5 UTP; 100BASE-TX: Cat 5/5e UTP; 1000BASE-T: Cat 5/5e/6 UTP (All Max 100m)

ButtonReset

Power Supply12VDC / 2A Adapter

Wi-Fi Frequency & Signal Rate2.4 GHz: 574 Mbps; 5 GHz: 2402 Mbps (HE160)

Flash128 MB NAND

DRAM512 MB DDR4

LED IndicatorsSYS, WLAN, SFP, LTE Signal, WAN (1000M/100/10M), WAN/LAN (1000M/100/10M)

Dimensions8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm); antenna excluded

AntennaWi-Fi: 3× 5GHz 5.5dBi & 2.4GHz 4.5dBi; LTE: 2× 4.0dBi

MountingDesktop / Wall

Max Power ConsumptionEU: 17.3W

IPS ThroughputTCP: 229 Mbps; UDP: 188 Mbps

DPI ThroughputTCP: 933 Mbps; UDP: 927 Mbps

GRE ThroughputUnencrypted: 545.3 Mbps; Encrypted: 282.6 Mbps

WireGuard VPN387.7 Mbps

Concurrent Sessions150,000

New Sessions / Sec5,100

NAT ThroughputStatic IP: 947.1 / 940.1 Mbps; DHCP: 949.2 / 941.1 Mbps; PPPoE: 942.6 / 941.1 Mbps; L2TP: 875.4 / 892.0 Mbps; PPTP: 881.2 / 895.8 Mbps

IPsec VPN ThroughputSHA1-AES256: 652.2 Mbps; SHA256-AES256: 654.4 Mbps; SHA384-AES256: 646.5 Mbps; SHA512-AES256: 670.5 Mbps

Other VPN ThroughputOpenVPN: 115.5 Mbps; L2TP: 990.0 / 475.0 Mbps; PPTP: 1177.9 / 177.4 Mbps; SSL VPN: 122.5 Mbps

Packet Forwarding Rate66 Byte: 1,453,489 / 1,453,488 pps; 1,518 Byte: 81,274 / 91,275 pps

Wireless FeaturesSeamless Roaming, Mesh (with EAP), OFDMA, Beamforming, MU-MIMO, SSID/Client Rate Limit, Airtime Fairness

Wireless EncryptionWPA/WPA2/WPA3 (Personal & Enterprise)

Multiple SSIDs16 total (8 per radio)
