Legrand
Разклонител Legrand 6 945 15
Артикул №: 1000027061
Категория:
Разклонители
61,99 €
✓ Налично във външен склад
Mechanical characteristics
Impact tests: IK 04
Protection against solid/bodies and liquids: IP 20
Material characteristics
Case: Black painted aluminium + dark grey PP
Non-slip feet: Plastic
Halogen-free
UV-resistant
Self-extinguishing:
750°C/30 s for insulating components holding live parts in place.
650°C/30 s for other insulating components.
Electrical characteristics
Voltage: 230 V~
Power: 3680 W MAX.
• 2P+E sockets: 16 A
• 2P sockets: 6 A (6 945 95)
10 A (6 945 96)
2.5 A (6 945 15)
• SPD: Uc: 275 V - 50 Hz
Uoc: 4 kV
Isccr: 3.0 kA
Up: 1 kV
Type: 3
SPD:
• The switch is set to ON and the green LED is lit: The SPD is active and
protects any plugged-in appliances.
• The switch is set to ON and the green LED is off: the SPD has protected
against lightning but is no longer protecting the plugged-in appliances.
Note: The multi-outlet adapter still works but is not protected.
Climate characteristics
Usage temperature: -5°C to +35°C
Storage temperature: -20°C to +70°C
Impact tests: IK 04
Protection against solid/bodies and liquids: IP 20
Material characteristics
Case: Black painted aluminium + dark grey PP
Non-slip feet: Plastic
Halogen-free
UV-resistant
Self-extinguishing:
750°C/30 s for insulating components holding live parts in place.
650°C/30 s for other insulating components.
Electrical characteristics
Voltage: 230 V~
Power: 3680 W MAX.
• 2P+E sockets: 16 A
• 2P sockets: 6 A (6 945 95)
10 A (6 945 96)
2.5 A (6 945 15)
• SPD: Uc: 275 V - 50 Hz
Uoc: 4 kV
Isccr: 3.0 kA
Up: 1 kV
Type: 3
SPD:
• The switch is set to ON and the green LED is lit: The SPD is active and
protects any plugged-in appliances.
• The switch is set to ON and the green LED is off: the SPD has protected
against lightning but is no longer protecting the plugged-in appliances.
Note: The multi-outlet adapter still works but is not protected.
Climate characteristics
Usage temperature: -5°C to +35°C
Storage temperature: -20°C to +70°C
Технически характеристики
| Impact tests | IK 04 |
| Case | Black painted aluminium + dark grey PP |
| Non-slip feet | Plastic |
| Напрежение | 230 V~ |
| • 2P+E sockets | 16 A |
| • 2P sockets | 6 A (6 945 95) |
| • SPD | Uc: 275 V - 50 Hz |
| Uoc | 4 kV |
| Isccr | 3.0 kA |
| Up | 1 kV |
| Тип | 3 |
| Usage temperature | -5°C to +35°C |
| Температура на съхранение | -20°C to +70°C |
