Range Extender/Удължител на обхват Tenda A9

Tenda A9

A9 is a wireless N300 universal range extender, specially designed to extend the exisiting WiFi coverage and improve the signal strength. With one button extension, smart signal LED, wall-mount design and universal compatibility, it is easy for users to boost wireless networking. A9 is an ideal choice for you to eliminate WiFi dead zones and optimize your networking.

What It Does

A9 is a wireless N300 universal range extender, specially designed to extend the exisiting WiFi coverage and improve the signal strength. With one button extension, smart signal LED, wall-mount design and universal compatibility, it is easy for users to boost wireless networking. A9 is an ideal choice for you to eliminate WiFi dead zones and optimize your networking.

Main Features

• 300 Mbps 802.11n speed.

• 2*3 dBi external antennas boost signal to extend WiFi coverage up to more 200㎡.

• One button extension help to extend WiFi coverage easily.

• Smart WiFi Signal Strength LED help to choose optimum location easily.

• Compatible with main brands 802.11n standard wireless routers and WiFi DSL.

• Support SSID Hiding

Strong Signal and Wide CoverageWith 2*3dBi external antennas , A9 can provide strong singal and extend the existing WiFi coverage to more 200㎡. Also, by optimizing the software and hardware, the anti-interference ability is improved much, so that A9 can provide stable signal and guarantee the large WiFi coverage.

Whole Coverage for Large Multi-rooms FlatFor the large multi-rooms flats, single wireless router can not provide a perfect WiFi environment and there are always WiFi dead zones at the balcony, study or bathroom and so on. It is easy to realize WiFi coverage for the whole flat by placing an A9 at the right place according to the signal LED (the LED should be GREEN), and boosting the signal to the whole flat.

Data Rate 802.11b : 11 Mbps

802.11g : 54 Mbps

802.11n : 300Mbps

Standard&Protocol IEEE802.11b,IEEE 802.11g, IEEE 802.11n

Modulation 802.11b: DSSS / BPSK / QPSK / CCK

802.11g: OFDM / DSSS / BPSK / QPSK / CCK

802.11n: OFDM / DSSS / BPSK / QPSK / CCK

Frequency 2.412~2.484 GHz

Power 16dBm

Reception Sensitivity 11b: -95dBm 11g: -76dBm 11n: -73dBm

Antenna

2 *3dBi external non-detachable

Standard Version RFC768 UDP

RFC791 IP

RFC792 ICMP

RFC793 TCP

Channel Bandwidth: 20/40MHz (default)

Working Mode Repeater Mode (Client + AP)

Wireless Security Encryption Mode: Mix WPA-PSK/WPA2-PSK

WPA Algorithm: TKIP
