Охлаждане за процесор Arctic Freezer 4U-OneX
Arctic Freezer 4U-OneX
Compatible with 4U Server ChassisWith 53 mm of RAM clearance, memory modules with moderate heatsinks can be used easily. Its optimized installation height of just 151 mm allows it to fit into standard 4U server racks as well as most consumer 4U cases.
Designed for Continuous OperationThe Freezer 4U-OneX is equipped with dual ball-bearing fans, enabling reliable 24/7 continuous operation. Each fan delivers up to 81 CFM with high static pressure, making them ideal for use even in high-density systems.Powerful Fans in Push-Pull ConfigurationThe dual configuration also allows for inherent redundancy and protects the system from total shutdown caused by heat. To adjust the airflow direction the fans can be easily swapped over.
Характеристики
| Thermal Interface Material | Да |
| MX-7 (0.8 g) | Да |
| Thermal Pad (40 x 6.3 x 2.0 mm) | x 2 |
| Thermal Pad (27 x 7.5 x 2.0 mm) | x 2 |
| Гаранция | Да |
| Years | 6 |
| Operating Ambient Temperature | Да |
| 0—40 °C | Да |
| Размери | Да |
| 124 (L) x 151 (B) x 156 (H) mm | Да |
| Нето тегло | Да |
| 1479 g | Да |
| Съвместимост | Да |
| Ampere | Да |
| LGA5964 | Да |
| Heatsink Specification | Да |
| Heat Pipe | Да |
| Ø 6 mm | x 8 |
| Number of Fins | Да |
| 57 | Да |
| Fin Material | Да |
| Aluminium | Да |
| Fan Specifications | Да |
| Fan | Да |
| 2x 120mm PWM Fans | Да |
| Fan Speed | Да |
| 400-3300 rpm, PWM Controlled | Да |
| Fan Bearing | Да |
| Dual Ball Bearing | Да |
| Typical Voltage | Да |
| V DC | 12 |
| Start Up Voltage | Да |
| V DC | 3,1 |
| Ток | Да |
| 0,29 A | Да |
| Дължина на кабела | Да |
| Mm | 300 |
| Конектор | Да |
| 4-Pin Buchse | Да |
