Ledvance
LED прожектор Ledvance FL PFM 10 W 3000 K SYM 100 S BK
Артикул №: 1000136375
Категория:
Електрически крушки
30,99 €
✓ Налично във външен склад
Product benefits
- Bright, robust and durable
- Demand optimized illumination due to flexible and programmable sensor
- Easy adjustment of sensor range, daylight detection and hold time
- Always-on override, activated via special mains switching pattern
- Safe and very uniform illumination, due to frosted and tempered glass diffuser
- No upper light output ratio (ULOR 0%) when mounted at 0° tilt
- Energy savings of up to 90 % compared to halogen lamp floodlights
Areas of application
- Replacement for floodlights with halogen lamps
- Outdoor use (IP65)
- Public areas
- Building facades
- Construction areas
- Gardens, balconies and other outdoor areas
Product features
- Flexible motion and daylight sensor
- Sensor with 350° pan and 180° tilt
- Reflector-based, symmetric light distribution with 100° x 100° beam angle
- Integrated wide voltage driver, suitable for 100 - 277 V AC
- Surge protection: up to 4 kV (L/N-PE), 2 kV (L-N)
- Mounting bracket with 30° angle and wide rotation area
- Pre-installed, flexible 1 m cable (H05RN-F), wrapped 3 x 1.0 mm² single wires
Характеристики
| Nominal wattage10.00 W | Да |
| Nominal voltage100…277 V | Да |
| Mains frequency50…60 Hz | Да |
| Nominal current48 mA | Да |
| Inrush current7.2 A | Да |
| Inrush current time Th5021 µs | Да |
| Power factor λ> | 0.90 |
| Total harmonic distortion | Да |
| Photometrical data | Да |
| Luminous flux1100 lm | Да |
| Luminous efficacy110 lm/W | Да |
| Color temperature3000 K | Да |
| Light color (designation)Warm White | Да |
| Color rendering index Ra≥80 | Да |
| Standard deviation of color matching≤5 sdcm | Да |
| Luminous intensity- | Да |
| Flickering metric (Pst LM)- | Да |
| Stroboscope effect metric (SVM)- | Да |
| Photobiological safety group acc. to EN62778RG1 | Да |
| Photobiological safety group acc. to EN62471RG1 | Да |
| Beam angle100 ° x | 100 ° |
| Dimensions & Weight | Да |
| Length159.00 mm | Да |
| Height53.00 mm | Да |
| Width131.00 mm | Да |
| Product weight440.00 g | Да |
| Cable length1000 mm | Да |
| Materials & Colors | Да |
| Product colorBlack | Да |
| Housing colorBlack | Да |
| Body materialAluminum | Да |
| Light emitting surface materialGlass | Да |
| Glow Wire Test according to IEC | 60695-2-12650 °C |
| Mercury content0.0 mg | Да |
| Application & Mounting | Да |
| Ambient temperature range-30…+50 °C | Да |
| Temperature range at storage-40…+70 °C | Да |
| Type of connectionCable, | 3-pole |
| Type of protectionIP65 | Да |
| Protection class IK (shock resistance)IK07 | Да |
| DimmableNo | Да |
| Mounting typeSurface | Да |
| Mounting locationWall, Ceiling | Да |
| Application environmentOutdoor | Да |
| AdjustableYes | Да |
| LED module replaceableNot replaceable | Да |
| With light sourceYes | Да |
| Lifespan | Да |
| Lifespan L70/B50 at | 25 °C70000 h |
| Lifespan L80/B10 at | 25 °C55000 h |
| Lifespan L90/B10 at | 25 °C35000 h |
| Number of switching cycles100000 | Да |
| Control gear | Да |
| Output current220 mA | Да |
| ECG - Output ripple current | Да |
| Sensor | Да |
| Type of sensorMotion, Light | Да |
| Sensor technologyPassive infrared/Photocell | Да |
| Sensor detection angle40 °…160 ° | Да |
| Sensor controlled switching time10 s…12 min | Да |
| Detection range of motion sensor2…12 m | Да |
| Detection threshold of daylight sensor10…2000 lx | Да |
| Sensor IP ratingIP65 | Да |
| Certificates & Standards | Да |
| StandardsCE, CB, ENEC, EAC, RoHS, EPD | Да |
