LED лампа Ledvance DP Slim Value 1500

Product benefits

• Evenly distributed light
• Energy savings of up to 50 % (compared to luminaires that use fluorescent lamps)
• Very slim housing
• Easy installation as mounting brackets can be positioned freely on the luminaire
• Tool-free electrical connection due to push button connector
• Easy access to electrical terminal thanks end caps with clip mechanism

Areas of application

• Industrial and storage facilities
• Car parks and underpasses
• Garages
• Workshops, assembly lines

Product features

• High luminous efficacy: up to 110 lm/W
• Beam angle: 120°
• Type of protection: IP65

Electrical data

Nominal wattage50.00 W

Nominal voltage220…240 V

Mains frequency50…60 Hz

Nominal current270 mA

Inrush current7 A

Inrush current time Th5060 µs

Max. number of luminaires per miniature circuit breaker B1655

Max. number of luminaires per miniature circuit breaker C1035

Max. number of luminaires per miniature circuit breaker C1655

Power factor λ≥0.90

Protection classII

Operating modeIntegrated LED driver

Photometrical data

Luminous flux5500 lm

Luminous efficacy110 lm/W

Color temperature4000 K

Light color (designation)Cool White

Color rendering index Ra> 80

Standard deviation of color matching≤5 sdcm

Photobiological safety group acc. to EN62778RG0

Beam angle120 °

Dimensions

Length1500.00 mm

Height48.00 mm

Width35.00 mm

Materials & Colors

Product colorWhite

Housing colorWhite

Body materialPolycarbonate (PC)

Cover materialPolycarbonate (PC)

Light emitting surface materialPolycarbonate (PC)

Glow Wire Test according to IEC 60695-2-12650 °C

Mercury content0.0 mg

Application & Mounting

Ambient temperature range-20…+40 °C

Temperature range at storage-30…+70 °C

Type of connectionScrewless terminal, 2-Pole

Type of protectionIP65

Protection class IK (shock resistance)IK08

DimmableNo

Mounting typeSuspended/Surface

Mounting locationCeiling

Application environmentIndoor

LED module replaceableNot replaceable

Lifespan

Lifespan L70/B50 at 25 °C30000 h

Lifespan L80/B10 at 25 °C27000 h

Lifespan L90/B10 at 25 °C20000 h

Number of switching cycles100000

Control gear

Output current590 mA

Certificates & Standards

StandardsCE, CB

Luminaire with limited surface temperature, "D sign"Yes

Ball shot safeNo
