Кутия Cooler Master HAF 500
Cooler Master’s classic HAF series is making a return with HAF 500. Built for high airflow and peak performance, the HAF 500 boasts iconic 200mm large intake ARGB fans, ensuring unparalleled intake and cooling efficiency. The chassis features a dedicated GPU fan, adjustable to various GPU lengths. Ample clearance for dual 360mm radiators on the top and front panel accommodates the most advanced water cooling setups.
Tool-less side panels and a removable top panel facilitates simplified, hassle-free component installation without the need to struggle with small spaces.
Large filtered intakes promotes high airflow, keeping internal components running at optimal temperature.
Iconic 200mm ARGB fans embedded in the core of the HAF Series in design and function move high volumes of air quietly and effectively due to their large size. Utilizing the included hub, ARGB lighting can be customized to create a comprehensive theme to match your build.
The tempered glass side panel is secured with pins for easy removal, facilitating quick access to the internals without the use of tools. An optional screw can be installed to further secure the tempered glass side panel.
Support for up to eight 120mm fans and dual 360mm radiators on the top and front panel ensure high compatibility for liquid-cooled systems.
Dimensions (L x W x H)516 x 224 x 510mm (incl. Protrusions)
Motherboard SupportITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12" x 14.1", may impact cable management and case features, remove cable cover and GPU fan bracket features)
Характеристики
| Cooler Master HAF 500 | |
| Homecoming Classic | |
| Mesh Front Panel | |
| Dual 200MM ARGB Fans | |
| Screwless & Tool-free TG Side Panel Design | |
| Versatile Cooling Options | |
| Exterior ColorBlack, White | |
| Materials - OutlookSteel, Mesh, Plastic | |
| Materials - Side PanelTempered Glass, Steel | |
| Expansion Slots7 | |
| 5.25" Drive BaysN/A | |
| 2.5" / 3.5" Drive Bays (combo)2 | |
| 2.5" Drive Bays2 | |
| I/O Panel2x USB 3.2 Gen 1 (formerly USB 3.0), 1x USB 3.2 Gen 2 Type-C, 1x single Audio Jack, 1x Reset/ARGB button | |
| ARGB ControllerARGB Hub | |
| Pre-installed Fans - Front2x 200mm ARGB Fan | |
| Pre-installed Fans - Rear1x 120mm SickleFlow PWM ARGB | |
| Pre-installed Fans - Others1x 120mm SickleFlow PWM (GPU Fan) | |
| Fan Support - Top3x 120mm, 2x 140mm, 2x 200mm | |
| Fan Support - Front3x 120mm, 2x 140mm, 2x 200mm, *200mm Mounting Hole Spacing 154 x 154 w/ up to 30mm thickness | |
| Fan Support - Rear1x 120mm | |
| Fan Support - Top on HDD cage1x 120mm | |
| Radiator Support - Top120mm, 140mm, 240mm, 280mm, 360mm | |
| Radiator Support - Front120mm, 140mm, 200mm, 240mm, 280mm, 360mm | |
| Radiator Support - Rear120mm | |
| Clearance - CPU Cooler167mm/6.5" | |
| Clearance - PSU180mm/7.1" | |
| Clearance - GFX410mm/16.1" | |
| Cable Routing - Behind Motherboard Tray30mm | |
| Dust FiltersTop, Bottom | |
| Power Supply SupportBottom mount, ATX |
