Контролер за соларна система TP-Link VIGI PS90

VIGI PS90

VIGI Solar System Controller

• 93.6Ah/10.95V Automotive-Grade Lithium Battery (31.2Ah Per Lithium Battery)
• Remote Management and Maintenance via the VIG app or VIGI Cloud VMS
• Indendent Protection Circuit Ensures Battery Safety and Uninterrupted Device Operation
• Intelligent Auxiliary Heating Technology Ensures Optimal Battery Performance in Extreme Cold Weather
• Maximum Power Point Tracking (MPPT) Charging Controller Increases Charging Efficiency by 20%*
• Remaining Capacity > 70%** after 500 Cycles
• IP66 Weatherproof

Remote Management

Equipped with a built-in MPPT Controller, VIGI PS90 integrates seamlessly with network devices, allowing centralized control via the VIGI app or VIGI Cloud VMS. Remotely monitor power statistics, receive low-battery alerts, update firmware, and reboot the system—all without needing on-site presence. Enjoy peace of mind, wherever you are.

Independent Protection Circuit

Each individual battery has its own protection circuit, which prevents failures in one battery from affecting the entire battery pack. This design ensures battery safety and uninterrupted device operation.

Category:

BATTERY

TypeLithium

Intelligent Auxiliary HeatYes

Battery Capacity93.6Ah (Max), 31.2Ah (Per Lithium Battery)

Voltage10.95 V

Max. Output Voltage12.6 V

LifeMore than 500 cycles

Dimension9.4 × 2.9 × 2.8 in (240 × 74 × 72 mm) (Per Lithium Battery)

Charging Condition0°C45°C-30°C45°C (With intelligent auxiliary heating)

Discharging Condition-20°C60°C-30°C60°C (With intelligent auxiliary heating)

HARDWARE

Interface1× Three-pin Female Connector (To Controller)1× Three-pin Male Connector (To Battery)2× Four-pin Female Connectors (To Solar Panel)1× 10/100 Mbps RJ453× 5.5mm DC Power Plugs (#1, #2: 9V-12.6VDC/2A, #3: 12VDC/2A)

Indicator LED6 LEDs: 1× SYS, 1× LAN, 1× PV, 3× BATColor: Blue
